Ex-e M12 Nickel Plated Brass Extreme Temp FKM Insert Standard Elongated Thread Dome Cable Gland | Cord Grip | Strain Relief CD12DR-RX

Ex-e M12 Nickel Plated Brass Extreme Temp FKM Insert Standard Elongated Thread Dome Cable Gland | Cord Grip | Strain Relief CD12DR-RX
3D CAD VIEWER
Sealcon #: CD12DR-RX
Cable Range: 0.08" - 0.2" (2 to 5 mm)
Color: Nickel
Material: Nickel Plated Brass
Hummel: HSK-M-PVDF-Ex
Hummel #: 1.660.1200.31

Locking Nut Sold Separately

Add to Quote
Need Technical Assistance?
Give our technical sales team a call
(303) 699-1135 | (800) 456-9012
Hole Diameter (A)0.47" (12 mm)
Body Length (B)0.75" (19 mm)
Thread Length (D)0.39" (10 mm)
Wrench Flat (F1)0.55" (14 mm)
Suggested Clearance Hole for Non-Threaded Mounting
PDF DOWNLOADS
Catalog Page
  • Materials
      Operating Temperature
      -20C° to 130C° (-4°F to 266°F)


    RELATED ACCESSORIES

    Nickel Plated Brass Locking Nut M12 X 1.5 | NM-12-BR
