Ex-e M16 Nickel Plated Brass Extreme Temp FKM Insert Standard Elongated Thread Dome Cable Gland | Cord Grip | Strain Relief CD16DR-RX

Ex-e M16 Nickel Plated Brass Extreme Temp FKM Insert Standard Elongated Thread Dome Cable Gland | Cord Grip | Strain Relief CD16DR-RX
3D CAD VIEWER
Sealcon #: CD16DR-RX
Cable Range: 0.08" - 0.24" (2 to 6 mm)
Color: Nickel
Material: Nickel Plated Brass
Hummel: HSK-M-PVDF-Ex
Hummel #: 1.660.1600.31

Locking Nut Sold Separately

Add to Quote
Need Technical Assistance?
Give our technical sales team a call
(303) 699-1135 | (800) 456-9012
Hole Diameter (A)0.63" (16 mm)
Body Length (B)0.83" (21 mm)
Thread Length (D)0.39" (10 mm)
Wrench Flat (F1)0.67" (17 mm)
Wrench Flat (F)0.75" (19 mm)
Suggested Clearance Hole for Non-Threaded Mounting
PDF DOWNLOADS
Catalog Page
  • Materials
      Operating Temperature
      -20C° to 130C° (-4°F to 266°F)


    RELATED ACCESSORIES

    Nickel Plated Brass Locking Nut M16 X 1.5 | NM-16-BR
