PG21 Gray Nylon Standard Flex Multi-Hole (4 Holes) Cable Gland | Cord Grip | Strain Relief CF21A8-GY

Sealcon #: CF21A8-GY

Color: Gray

Material: Nylon

Number of Holes: 4

Diameter of Holes: 0.2" (5.2 mm)

Insert Part Number: 1.089.2107.19

Hummel: HSK-K-Flex

Hummel #: * Custom

Locking Nut & O-Ring Sold Separately

Add to Quote

Need Technical Assistance?
Give our technical sales team a call
(303) 699-1135 | (800) 456-9012

Body Length (B)	1.22" (31 mm)
Thread Length (D)	0.55" (14 mm)
Wrench Flat (F1)	1.3" (33 mm)

PDF DOWNLOADS

Catalog Page

Features
Flame protected – V0 Rated according to UL 94Halogen- and Phosphorous free materials
Safety – Ratchet to prevent Dome from coming loose under vibration
Large Selection – Cable Range from .08″ (2mm) to 1.38″ (35mm)
Non-Corrosive – Resistant to salt water, weak acids, weak alkalis, alcohol, esters, ketones, ether, gasoline, mineral, animal & vegetable oil.
Durable – Rugged Construction
Environmentally compliant – RoHS & Deca BDE

This Nylon Strain Relief (Cable Gland) with PG 21 Thread will provide your application with a product made of exceptional quality

The self locking ACME thread on the dome and flex top ensures that the overlapping splines apply a concentric seal, thereby preventing the form seal from being pulled out of the fitting & ensuring pull-out protection of your cable without damaging it.

Materials

Fittings: Nylon 6/6
Form Seal: Elastomer
Optional ORing: Buna-N, FPM or Silicone
Optional Seal Ring: Polyethylene or Fiber-Reinforced Plastic

Operating Temperature
-40C° to 100C° (-40°F to 212°F)

Available Colors
Black (RAL 9005);Gray (RAL 7035)

Nylon 6/6: V0-rated - Flame resistant, halogen and phosphorous free, self-extinguishing, non-toxic, fungus resistant.

UL F1 UV Stable Rating for outdoor applications (Black Nylon version only).

All Multi-Hole Fittings in Nylon and Nickel Plated Brass have UR (ONLY)
