M25 x 1.5 Gray Nylon Standard Flex Multi-Hole (4 Holes) Cable Gland | Cord Grip | Strain Relief CF25M8-GY

Home » Cable Gland Strain Relief » Nylon PG, NPT, Metric Thread Types » Metric Threads » Multi-Hole Cable Gland » Flex Multi-Hole Cable Glands » M25 x 1.5 Gray Nylon Standard Flex Multi-Hole (4 Holes) Cable Gland | Cord Grip | Strain Relief CF25M8-GY

Sealcon #: CF25M8-GY

Color: Gray

Material: Nylon

Number of Holes: 4

Diameter of Holes: 0.2" (5.2 mm)

Insert Part Number: 1.089.2107.19

Hummel: HSK-K-Flex

Hummel #: * Custom

Locking Nut & O-Ring Sold Separately

Need Technical Assistance?
Give our technical sales team a call
(303) 699-1135 | (800) 456-9012

PDF DOWNLOADS

Features
This Nylon Strain Relief (Cable Gland) with M25 x 1.5 Thread will provide your application with a product made of exceptional quality

The self locking ACME thread on the dome and flex top ensures that the overlapping splines apply a concentric seal, thereby preventing the form seal from being pulled out of the fitting & ensuring pull-out protection of your cable without damaging it.
Materials
- Fittings: Nylon 6/6
- Form Seal: Elastomer
- Optional ORing: Buna-N, FPM or Silicone
- Optional Seal Ring: Polyethylene or Fiber-Reinforced Plastic
Operating Temperature
-40C° to 100C° (-40°F to 212°F)
Available Colors
Black (RAL 9005);Gray (RAL 7035);Blue (RAL 5012) - upon request;

Nylon 6/6: V0-rated - Flame resistant, halogen and phosphorous free, self-extinguishing, non-toxic, fungus resistant.

UL F1 UV Stable Rating for outdoor applications (Black Nylon version only).

*Sizes 3/8” NPT, M12, M16, PG7, PG9, and PG11 and all Multi-Hole Fittings in Nylon and Nickel Plated Brass have UR (ONLY)
APPROVALS
