Hensel ENYCASE Thermoplastic Cable Junction Box | EB ENYCASE G – without Terminals | EB25G

Sealcon #: EB25G
Size: EB ENYCASE G - without Terminals
Material: EB 170 x 220 x 96 mm
Hensel #: EB 25 G
Cover screws and mounting screws included.

Built-in dimensions W 170 x H 220 x D 96 mm
For installation equipment on DIN rails or mounting plates (order separately)
With opaque lid
Fastener for tool operation
Sealable
Box walls without knockouts
External brackets for wall fixing included

Need Technical Assistance?
Give our technical sales team a call
(303) 699-1135 | (800) 456-9012
PDF DOWNLOADS
Catalog Page
  • Rated insulation voltage Ui = 1000 V a.c./d.c.
    Impact strength IK 09 (10 Joule)
    Static load mounting plate or DIN rail = 4.4 kg
    Lid = 1.2 kg
    Power dissipation capability at Δϑ = 40 K Pde = 20 watts
    Wall thickness ümbris = 2.5 mm
    Lid = 2 mm
    Material PC-GFS (polycarbonate)
    Degree of protection IP 66
    Mounting width 220 mm
    Mounting height 170 mm
    Max. installation depth 96 mm
    Width 255 mm
    Height 205 mm
    Depth 112 mm
    Weight 0,645 kg
    In accordance with IEC 62208:2011
    Impact
    IK 09 (10 Joule)
    Fire Resistance
    Glow wire text in accordance with IEC 60695-2-11 650° C for boxes
