Sealcon #: FSM16KL1416
(housing only)
M12 Power Connector Coding K+L Kit
Material: Nickel Plated Brass
Kit includes: M12 Power Connector, Pins & Sockets, K+L coded Inserts.
View Technical Data for more Information
Need Technical Assistance?
Give our technical sales team a call
(303) 699-1135 | (800) 456-9012
Give our technical sales team a call
(303) 699-1135 | (800) 456-9012
-
Features
• Power transmission to 16A and 630V
• Protection IP67 and IP69K
• Cable diameter 3-11 mm (.12″- .43″)
• EMI (EMC) Shielding in standard version
• K, L (Coding (5 positions)
• Robust metal housing
• Compact designs
• Optional stainless steel
• UL Certified -
TYPE: Power or Signal
PIN-OUT: 4, 5 (4 + PE)
AWG: K & L Crimp: 14-16
AMPERE: 12 - 16A
VOLT: 63 - 630V
CABLE RANGE: 3-11 mm (.12"- .43")
TEMPERATURE: -40°F to 257°F (-40°C to 125°C)
OPTIONS: Threaded, Over mold cord sets, 316L Stainless Steel, Black Chrome-Plated.
UNIQUENESS: Low profile, High power transmission, IP67 & IP69K, Robust metal housing, EMI ready UL, VDE.
APPLICATIONS AC / DC Motors, Motor Control Switches, Aux. Power Distribution, LED &Conventional Lighting, Network Devices, Robotics.
UL approval UL (Listed Underwriters Laboratories)
