Application area: Suitable for outdoor installation.

Resistant to occasional cleaning procedures (direct jet)
Resistant to occasional cleaning procedures (direct jet) with high-pressure cleaner without additives, water pressure: max. 100 bar, water temperature: max. 80° C, distance => 0,15 m, in accordance with the requirements IP 69K, enclosure and cable glands at least IP 65

Ambient temperature
Average value over 24 hours + 55° C
Maximum value + 70° C
Minimum value - 25° C

Fire protection in the event of internal faults: Demands placed on electrical devices from standards and laws Minimum requirements - Glow wire test in accordance with IEC 60 695-2-11: - 650°C for boxes and cable glands - 850°C for parts of insulating material necessary to retain current carrying parts in position

Fire protection in the event of specific risks or hazards:
Demands placed on electrical installations and devices in areas and facilities subject to fire risk, e.g. DIN VDE 0100 Part 482, official regulations, VdS directives Minimum requirements - Glow wire test to IEC 60 695-2-11: - 850°C for boxes and cable glands - 850°C for cavity wall installation - Use of fire resistant cables

Burning behavior:
Glow wire test IEC 60 695-2-11: 960° C
UL Subject 94 V-0
flame resistant self-extinguishing

Degree of protection against mechanical load: IK09 (10 Joule)

Toxic behavior
halogen-free silicone-free "halogen-free" in accordance with the examination of the cables and insulated wires - corrosiveness of fumes - as per IEC 754-2

APPROVALS

• VDE approval VDE (Association of German Electrical Engineers)
• German Lloyd
