M32 x 1.5 Nickel Plated Brass EMI / RFI Acid and Chemical Resistance FKM Insert Reduced Dome Cable Gland | Cord Grip | Strain Relief VC32MR-BR

Sealcon #: VC32MR-BR
Cable Range: 0.63" - 0.98" (16 to 25 mm)
Color: Nickel
Material: Nickel Plated Brass
Hummel #: 1.752.3200.50

Particularly suitable for applications in the process industry that require “Acid and Chemical Resistance” or are dealing with direct environmental influences.

  • Operating Temperature: -20°C to 180°C (-4°F to 356°F)
  • Cable Range: 0.63″ – .98″ (16 – 25 mm)
  • Housing: Nickel Plated Brass
  • Form Seal: FKM
  • O-Ring: FKM
  • Sizes: M32
  • EMI (RFI): Ready

Locking Nuts Sold Separately!

Need Technical Assistance?
Give our technical sales team a call
(303) 699-1135 | (800) 456-9012
Hole Diameter (A)1.26" (32 mm)
Body Length (B)1.34" (34 mm)
Thread Length (D)0.31" (8 mm)
Wrench Flat (F1)1.42" (36 mm)
Wrench Flat (F)1.57" (40 mm)
PDF DOWNLOADS
Catalog Page
  • Features

    VariaPro Chem

      • is particularly suitable for applications in the process industry that require

    “Acid and Chemical Resistance”

      • or are dealing with direct environmental influences.



    • Operating Temperature: -20°C to 180°C (-4°F to 356°F)
    • Housing: Nickel Plated Brass
    • Form Seal: FKM
    • O-Ring: FKM

    The slim structure of the VariaPro is striking. It thereby meets the requirements for a space saving solution. In addition this cable gland is easily installed. The EMI (RFI) feature is already integrated as standard solution. The housing is made of nickel plated brass.

    This VariaPro Temp cable gland is available in four sizes M20, M25, M32 and M40. Thanks to the intelligent combination of seal inserts and reducers, VariaPro Temp can accommodate cables of diameters from 0.28″ to 1.26″ (7 to 32 mm).



  • Materials
    • Fittings: Nickel Plated Brass
    • Form Seal: FKM
    Operating Temperature
    -20C° to 180C° (-4°F to 356°F)


  • APPROVALS

    RELATED ACCESSORIES
